Self adjusting manual & automatic welding machine

MMA-200

         Self adjusting manual & automatic welding machine

• High Inverter frequency greatly reduces the weight of the welder.
• Great reduction in magnetic and resistance loss obviously enhances the welding efficiency and energy saving effect.
• Switching frequency is beyond audio range, which almost eliminates noise pollution.
• Advanced control technology meets various welding application and greatly improves the welding performance.
• It can be widely used in acid and electrode welding.
• Easy arc starting. less spatter, stable current and good shaping.
• Efficiency, energy saving, portable, stable arc, high no-load voltage, and with good compensation of arc force, are able to meet various welding requirement in field work.

Working voltage (V)                            1-110/220V

Frequency (Hz)                                       50/60

Rated input current (A)                              48

No-load voltage (V)                                    68

Output current (A)                                   20-200

Rated output voltage (V)                            21-28

Duty cycle (%)                                            60

Effiency (%)                                               85

Power factory                                              0.7

Insulation class                                            F

Protection class                                         IP21s
